Chinese High quality wpo series reduction gear box high speed gearbox china wpa size100 ratio 40 wpa speed reducer
WP stepper motor worm gear/worm gear speed reducer/AC worm gearbox
1.Widely used in light industry, good resistance to wearing, with high precision in dimensions, lower noise, advanced centric
running castings
2. The housing is of strong hardness, compact structure
3. Stable transmission, low vibration, large ratio, canbe matched with various machines
1.Housing:iron cast
2. low noise(<50DB)
3.Model:WPA 40-250,Ratio:10 to 60
4.Efficient and safe operating
5.ISO9001,Factory price,OEM
6.Technology Data:
| Type: | gearbox WPA |
| Model: | WPA 40-250 |
| Ratio: | 1:10,15,20,25,30,40,50,60 |
| Color: | Blue/Silver Or On Customer Request |
| Material: | Housing: Die-Cast Iron cast |
| Worm Gear-Copper-10-3# | |
| Worm-20CrMn Ti with carburizing and quenching, surface harness is 56-62HRC | |
| Shaft-chromium steel-45# | |
| Packing: | Carton and Wooden Case |
| Bearing: | C&U Bearing |
| Seal: | NAK SKF |
| Warranty: | 1 Year |
| Input Power: | 0.06KW,0.09KW |
| Usages: | Industrial Machine: Food Stuff, Ceramics,CHEMICAL,Packing,Dyeing, Woodworking,Glass. |
IEC Flange: | 56B14, 63B14, 63B5, 63B5, 71B14,80B14 AND SO ON |
| Lubricant: | Synthetic&Mineral |
Packing Details: Standard carton/Pallet/Standard wooden case
Delivery Details : 15-30 working days upon payment
1.Payment Term: TT, L/C
2.Delivery time: about 30 days from receive payment.
3.We accept customized products as per your special requirement.
4.Guidelines for the Selection:Usually we can select one machine which is suitable for you with some informations from you,such as ratio/motor speed/mounting dimension/ out torque etc.
5.If the minimum order amount is in excess of $10000, there are preferential.
Q1: What information should I tell you to confirm the product?
A:Model/Size, Transmission Ratio, Shaft directions & Order quantity.
Q2: What can i do if I don't know which one I need?
A:Dont worry, Send as much information as you can, our team will help you find the right one you are looking for.
Q3: What is your product warranty period?
A:We offer one year warranty since the vessel departure date left China.
Q4: Are you trading company or manufacturer ?
A: We are factory.
Q5: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q6: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q7: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
