Good temperature characteristics
High reliability , MTBF: 3×104h
Thin design, small size, light weight
Lightweight design Easy to install
Super cost-effective
Model | SICA30G |
Range input | AC30A |
Turns ratio | 1:1000 |
Output | 30mA |
Linearity | ≤0.1% |
Phase difference nonlinearity | ≤5' |
Load capacity | ≤2V |
Input frequency response | 25Hz~5kHz |
Linear range | 0%~120% |
Case aperture |
Φ9mm
|
Overload capacity | 10 times the nominal input current value, lasting 1s, interval 300s, repeated 5 times |
Isolation and withstand voltage | 2.5kV/50Hz/min×1mA |
Working environment | Temperature: -40~85℃; Humidity: ≤95% (no condensation) |
Product output lead length | 0.6m~2.6m optional |
Waterproof level | IP65 |
Installation and fixing method | Can be fixed on the cable with cable ties |
Case and lead requirements | Low smoke flame retardant |
Material requirements | Anti-corrosion, no rust |
