High-Precision SICA600KY AC Current Transducer Transformer for Reliable Electrical Measurement

Raydafon Group introduces the High-Precision SICA600KY AC Current Transducer Transformer, offering reliable electrical measurements with superior accuracy and durability. Ideal for engineers and technicians in industrial and energy sectors, it ensures peace of mind by eliminating measurement errors. Its advanced design and robust construction set it apart from competitors, delivering unmatched performance. Get yours today for dependable results!

Send Inquiry

Product Description

High insulation between primary and secondary sides

Strong overload capacity, good temperature characteristics

High reliability, MTBF: 3×104h

Thin design, small size, light weight

Lightweight design, easy to install, high cost performance

Model	SICA600KY
Range input	0~±50V
Turns ratio	1:2000
Output	0.3mA
Linearity	≤0.1%
Phase difference nonlinearity	≤5'
Load capacity	≤2V
Input frequency response	25Hz~5kHz
Linear range	0%~120%
Case aperture	Φ9mm
Overload capacity	10 times the nominal input current value, lasting 1s, interval 300s, repeated 5 times
Isolation and withstand voltage	2.5kV/50Hz/min×1mA
Working environment	Temperature: -40~85℃; Humidity: ≤95% (no condensation)
Product output lead length	0.6m~2.6m optional
Waterproof level	IP65
Installation and fixing method	Can be fixed on the cable with cable ties
Case and lead requirements	Low smoke flame retardant
Material requirements	Anti-corrosion, no rust

Current isolation measurement, power supply monitoring, uninterruptible power supply UPS, welding equipment, railway locomotives, communication power supply, industrial automation control, electrochemistry
