Product Description

BM3 TECHNICAL DATA
TYPE		BM3Y-80	BM3Y-100	BM3Y-125	BM3Y-160	BM3Y-200	BM3Y-250	BM3Y-315	BM3Y-400	BM3Y-500
		BM3YS-80	BM3YS-100	BM3YS-125	BM3YS-160	BM3YS-200	BM3YS-250	BM3YS-315	BM3YS-400	BM3YS-500
		BM3YW-80	BM3YW-100	BM3YW-125	BM3YW-160	BM3YW-200	BM3YW-250	BM3YW-315	BM3YW-400	BM3YW-500
Displacement(ml/r)		80.5	100.5	126.3	160.8	200.9	252.6	321.5	401.9	476.5
Max.Pressure.Drop(Mpa)	cont.	20.5	20.5	20.5	20.5	20.5	20	20	15.5	12
	int.	27.5	27.5	27.5	26	25	25	24	19	14
	peak.	29.5	29.5	29.5	28	27	27	26	21	16
Max.torque(N.m)	cont.	226	282	355	451	564	684	870	813	728
	int.	293	365	459	559	672	845	1032	1021	903
	peak.	306	383	481	588	708	891	1091	1141	1044
Max. Speed (cont.)(r/min)		805	745	590	465	370	295	230	185	155
Max.Flow(cont.)(L/min)		65	75	75	75	75	75	75	75	75
Max.Output.Power(cont.)(Kw)		16	18	18	18	18	18	17	11	9
Weight(kg)		9.8	10	10.3	10.7	11.1	11.6	12.3	13.2	14.3
