Ammeter Electrical Current Sensor for Telecommunication Power Supply DC Motor

Raydafon Group's Ammeter Electrical Current Sensor for Telecommunication Power Supply DC Motor delivers precise monitoring with advanced tech, ideal for engineers in telecom and industrial settings, ensuring reliability and safety while enhancing efficiency and peace of mind—get yours today for superior performance!

Send Inquiry

Product Description

Based on the principle of electromagnetic conversion effect

High-precision, high-reliability output, fast response to various output currents and voltages,

Strong resistance to external magnetic field interference

Good long-term stability, no accumulated error

Model	SITD5P	SITD10P	SITD20P	SITD50P
Primary rated input current	DC0~5A	DC0~10A	DC0~20A	DC0~50A
Primary current measurement range	120%
Secondary side rated output	DC0~5V,0~10V,2~10V,4~20mA
Secondary rated output	DC9~36V,±12V,±15V,±24V
Current consumption	28+ISmA
Accuracy	≤±0.5%
Linearity	≤±0.2%
Offset voltage	T=25℃,≤±25mV
Temperature drift	≤±0.08%/℃
Response time	≤3μs
Load resistance	Current output ≤ 250Ω, voltage output>2kΩ
Tracking speed	≥50A/μs
Measurement bandwidth	DC~100kHz
Working temperature	-40℃~85℃
Storage temperature	-40℃~90℃
Isolation withstand voltage	2~6kV/50Hz/1min×1mA
Install	Card-mounted track installation, terminal wiring

Current isolation measurement, power supply monitoring, uninterruptible power supply UPS, welding equipment, railway locomotives, communication power supply, industrial automation control, electrochemistry
