Servo Planetary Gearbox

Servo Planetary Gearbox, Speed Gear Reducer Supplier in China

As a professional planetary gearbox manufacturer, Raydafon is specialized in producing planetary gear reducer for more than 20 years. All of Raydafon planetary gearboxes are designed with integral structure, that means the output planet carrier adopts double support structure design. The large span of the front and rear bearings is distributed inside the box body, forming a stable integrated structure to ensure high torsion rigidity and accuracy. They are widely used in servo applications.

• Raydafon planetary reducers are with the low backlash of 0-3 arc/min.
• 95% high efficiency of our planet gearboxes guarantees the excellent working performance of customer’s equipment.
• Our planetary speed reducers like coaxial gearboxes are designed with free of maintenance.
• High torque and high dynamic are the outstanding advantages of Raydafon precision gearboxes.
• Raydafon planetary gearboxes are specially designed for servo motors and stepper motors.
• High rigidity of Raydafon planetary gearhead is another outstanding features that users are particularly satisfied with.
• Quick positioning time of starting and stopping.
• Inertia and vibration are highly reduced.

Offered in concentric shaft, rightangle solid shaft and right angle hollow shaft designs with modular adaptor flanges and keyless compressible bushings to easily mount to any manufacturer’s servo motor.

Choose from standard backlash (<=15 arc-min),

low backlash (<=5-10 arc-min),

precision backlash (<= 3 arc-min) and zero backlash (<=1 arc-min).

Input speeds up to 6,000 RPM.

Ratios upto 100:1.

Nominal output torque upto 2400 Nm.
