small worm gearboxes for lift Small size: standard export packing (carton and pallet); Big size: fumigated wood carton or non-wood packing material carton About us We are one of the leading manufacturers of worm gearbox in China, specialized in gearbox industry for 22 years. Our products have bee......

small worm gearboxes for lift

Small size: standard export packing (carton and pallet);

Big size: fumigated wood carton or non-wood packing material carton



About us



We are one of the leading manufacturers of  worm gearbox in China, specialized in gearbox industry for 22 years. Our products have been reputed by our customers for long. Manufacturing according to the ISO9001 quality control system guidelines. We help our customer develop special gearbox for their application and OEM service offered.



Product features



1. WJ series worm reducer gear box adopt aluminium alloy or cast iron square housing, small size and elegant appearance.

2. It is flexible and convenient to install,steady running,efficent radiator,low noise,high carrying ability.

3. The products have been widely used for machinery equipment, such as  chemical, plating, ceramic, pharmaceutical, leather, foods,beverage,etc.



General Technical data



Housing materialZL108 Al-alloy or HT200 cast iron
Worm wheel materialZCuSn10Pb1
Worm gear material40Cr
Lubricating oilGB Gn230-460 Synthetic or Mineral oil
Efficiency50%~65%
Noise (MAX)60~68dB
Temp. rise  (MAX)50°C
Temp. rise (Oil)(MAX)60°C
Vibration20µm
Backlash20Arcmin
Brand of bearingsC&U or other brand requested
Brand of oil sealNAK--- Taiwan or other brands requested



ModelShaft Dia.(mm)Center HeightOutput Flange Dia.PowerRatioPermitted torqueWeight
Solid(h6)Hollow(h7) (mm)  (mm)(kw)(Nm)(KGS)
Wj30 141440 800.09~0.37.5~100221.5
Wj40 1918/1950 1100.12~0.57.5~100552.5
Wj50 252560 1250.18~0.77.5~1001204
Wj63 252572 1800.37~1.57.5~1001756
Wj75 282886 2000.55~37.5~1002809
Wj90 3535103 2100.75~47.5~10042513.5
Wj110 4242127.5 2701.1~5.57.5~10058543
Wj130 4545147.5 3201.5~7.57.5~10085067
Wj150 5050 170 320 2.2~15 7.5~100 1500100
Remark: the weight without motor



Rigid Tooth Flank Helical Gearbox for Leather Spanking Skirt Machine



Rigid Tooth Flank Helical Gearbox for Leather Spanking Skirt Machine



Rigid Tooth Flank Helical Gearbox for Leather Spanking Skirt Machine



Rigid Tooth Flank Helical Gearbox for Leather Spanking Skirt Machine





Combined system



Rigid Tooth Flank Helical Gearbox for Leather Spanking Skirt Machine



Packages



Rigid Tooth Flank Helical Gearbox for Leather Spanking Skirt Machine



Company Information



Rigid Tooth Flank Helical Gearbox for Leather Spanking Skirt Machine



Rigid Tooth Flank Helical Gearbox for Leather Spanking Skirt MachineRigid Tooth Flank Helical Gearbox for Leather Spanking Skirt MachineRigid Tooth Flank Helical Gearbox for Leather Spanking Skirt Machine



Rigid Tooth Flank Helical Gearbox for Leather Spanking Skirt MachineRigid Tooth Flank Helical Gearbox for Leather Spanking Skirt Machine



For more parameters and dimensions, please contact with us. Welcome to send us inquiry!
