Inline Planetary Gearbox

Right angle gearboxes (worm and planetary) are rugged and built for 90° turns. Inline reducers (parallel shaft and planetary) are an ideal match for motors with high input speeds, or when gearmotor efficiency is important. Contact our technical sales staff for help determining which gearbox solution is best for you

Raydafon worm gear reducers are designed with a hollow bore and allow for a corner turn with optional dual output. The reducers come in 12 ratios ranging from 5:1 to 100:1, with non-back-drivable ratios 30:1 and higher. Our right angle gearboxes are designed with five mounting options providing flexibility when incorporating the reducer into product.

The right angle bevel gearbox combines the features of our right angle worm and planetary inline reducers. With a solid and efficient right angle configuration, our right angle planetary gearboxes offer a robust solution. The right angle bevel gearbox comes in 18 ratios ranging from 5:1 to 1000:1, and it is back-drivable at all ratios.
