Hydraulic Piston Eaton Vickers MFB Inline Piston Motor MFB5U22 MFB5U20 MFB29U10 MFB10U31 MFB20UY10 MFB5UY22 MFB5UY20 MFB29UY10

MFB5U22

MFB5U20

MFB29U10

MFB10U31

MFB20UY10

432095

MFB5UY22

MFB5UY20

MFB29UY10

MFB10UY31

MFB45UY10

270531

857580

MFB5U21

MFB45U10

MFB20U10

MFB5UY21

292747

Model

Theoretical Displ. cm3/rev (in3/rev)

Flow L/min (USgpm) @ Rated r/min

Operating Speed r/min

Rated                Max

Pressure bar (psi)

Rated      Max

Output Torque Nm (lb in)

Rated              Max

Dry Weight kg (lb)

MFB5

10,5

(0.643)

19.0

(5.0)

1800

3600

100

(1500)

210

(3000)

15,25

(135)

30,5

(270)

5,0 (11)

MFB10

21,12

(1.29)

37,9

(10.0)

1800

3200

100

(1500)

210

(3000)

32,1

(284)

64,2

(568)

9,5 (21)

MFB20

42,8

(2.61)

75,7

(20)

1800

2400

100

(1500)

175

(2500)

50,85

(450)

101,7

(900)

18,5 (49)

MFB29

61,6

(3.76)

109,8

(29)

1800

2400

70

(1000)

140

(2000)

58,75

(520)

117,5

(1040)

18,5 (49)

MFB45

94,4

(5.76)

170,3

(45)

1800

2200

100

(1500)

210

(3000)

135,6

(1200)

271,2

(2400)

33 (73)
