High-Precision SIHD-KF3 Series Current Sensor with Low Drift and Fast Response for Reliable Electrical Measurement

Raydafon Group's High-Precision SIHD-KF3 Series Current Sensor delivers reliable electrical measurement with low drift and fast response, ideal for engineers and technicians in industrial automation. Its advanced technology ensures accuracy, reducing downtime and enhancing safety. Experience peace of mind with superior performance over competitors.

Send Inquiry

Product Description

Quick and easy installation

High precision, high reliability

Linear output, fast response

Various output currents and voltages

Strong resistance to external magnetic field interference

Good stability, no accumulated error

Model	-SIHD500KF3	SIHD1000KF3	SIHD1500KF3
Primary rated input current	DC500A	DC1000A	DC1500A
Primary current measurement range	120%
Secondary side rated output	DC0-5V,DC0-10V,4-20mA
Working power supply	±15V~±24V
Current consumption	28+ISmA
Accuracy	≤1%
Linearity	≤0.5%
Offset voltage	T=25℃,≤±25mV
Temperature drift	≤±0.08%/℃
Response time	Transmission output ≤150ms, tracking output ≤10μs
Load resistance	Voltage output ≥ 2kΩ, current output ≤ 250Ω
Tracking speed	≥50A/μs
Measurement bandwidth	DC~100kHz
Working temperature	-40℃~85℃
Storage temperature	-40℃~90℃
Isolation withstand voltage	2~6kV/50Hz/1min×1mA
Install	Screw fixing Terminal wiring

Current isolation measurement, power supply monitoring, uninterruptible power supply UPS, welding equipment, railway locomotives, communication power supply, industrial automation control, electrochemistry

Ever-Power Technology Co., Ltd. was established in 2010. It is a high-tech enterprise engaged in system research and development, production, sales and service in the fields of high-speed signal processing, electromechanical control, etc. The company is guided by military development, driven by scientific and technological innovation, and supported by talent development. It has been deeply involved in the electronics industry for more than ten years and has a high-quality, high-tech and high-level engineering and technical team. Electricity sensors, transmitters, and mutual inductors are the electricity isolation detection products launched by Ever-Power Technology in recent years in response to market demand and combined with the company's own product structure advantages. After years of continuous improvement and updating of this type of product, several major series and hundreds of specifications have been formed. The products are widely used in communications, instrumentation, metallurgy, railways, navigation, aerospace and other fields and are generally recognized by users.

Hot Tags: High-Precision Current Sensor Manufacturer, SIHD-KF3 Series Current Sensor Supplier, Low Drift Current Sensor Wholesale
