AWB-1600 2 ROWS Potato Harvester 800kg Potato Digger for Carrots, or Onions Without Damage

POTATO DIGGER - 2 ROWSA 2-row potato digger is a specialized agricultural implement designed to unearth potatoes from two rows simultaneously,streamlining the harvesting process for small to medium-scale potato farmers. Unlike a full harvester, a potato digger focuses primarily on lifting potatoes f......

Send Inquiry

Product Description

POTATO DIGGER - 2 ROWS

A 2-row potato digger is a specialized agricultural implement designed to unearth potatoes from two rows simultaneously,
streamlining the harvesting process for small to medium-scale potato farmers. Unlike a full harvester, a potato digger focuses primarily on lifting potatoes from the soil and leaving them on the surface for manual collection, rather than fully separating or conveying them.

Key Features
1. Dual Digging Blades: Equipped with two adjustable shares or blades that penetrate the soil beneath two potato rows
(typically spaced 60-90 cm apart).Blades lift potatoes along with some soil and vines, depositing them on the ground.

2. Vibrating or Static Sieves: Basic models use static blades to lift and loosen soil, while more advanced versions include vibrating sieves or chains to shake off excess dirt.

3. PTO-Driven Operation: Connects to the tractor’s PTO to power the digging mechanism, ensuring consistent performance.

4. Simple Design: Lightweight and compact compared to harvesters, with fewer moving parts, making it easier to maintain and operate.

5. Adjustable Depth: Allows customization of digging depth to suit different soil conditions and potato planting depths.

For more details, please click here to contact us!

TECHNICAL DATA	AWB-1600	AWB-1600 A
weight	800kg	1000kg
Rows	2
Tractor requirements
Input speed p.t.o.-shaft	540 RPM	540 RPM
Engine power (min.)	75 cv	85 cv
Required control valves	-	-
Working speed	3 - 5 Km/h

Applications
Small to Medium Farms: Ideal for operations with 1-20 acres of potatoes where manual labor is still practical.

Organic Farming: Suits growers who prefer hand-picking to ensure quality control and minimize machinery use.

Mixed Crop Farms: Useful for farmers growing potatoes alongside other crops, as it’s a multi-purpose digging tool.

Seed Potato Production: Allows careful manual collection to avoid damaging delicate seed potatoes.

How It Works
1. Setup: The digger is attached to a tractor via a three-point hitch or tow bar, and the PTO shaft is connected.

2. Digging: As the tractor moves forward, the two blades cut into the soil beneath the potato rows, lifting the tubers, soil, and vines.

3. Separation: The lifted material passes over a sieve or conveyor (if equipped), where vibration or gravity removes some soil,leaving potatoes exposed on the surface.

4. Collection: Workers follow behind to manually pick up the potatoes, which are left in neat rows or piles.

Comparison of ABC three models of products

Q: Are you trading company or manufacturer ? A: Our group consists in 3 factories and 2 abroad sales corporations. Q: Do you provide samples ? is it free or extra ? A: Yes, we could offer the sample for free charge but do not pay the cost of freight. Q: How long is your delivery time ? What is your terms of payment ? A: Generally it is 40-45 days. The time may vary depending on the product and the level of customization. For standard products, the payment is: 30% T/T in advance ,balance before shippment. Q: What is the exact MOQ or price for your product ? A: As an OEM company, we can provide and adapt our products to a wide range of needs.Thus, MOQ and price may greatly vary with size, material and further specifications; For instance, costly products or standard products will usually have a lower MOQ. Please contact us with all relevant details to get the most accurate quotation. If you have another question, please feel free to contact us.

FOR MORE DETAIL, PLEASE CONTACT US.
