Description | Angular Gearboxes A-3A 5:1 |
Application | * Various (agricultural) applications * Hole borer |
Consists of | * Gearbox * Order oil |
Technical information | * If you have any questions regarding performance at different speeds, please do not hesitate to contact us * When using for the first time, replace the oil after 50 operating hours |
Contains oil | No |
Max. oil capacity | 0.6 l |
Max. oil change interval | 500 h |
Oil SAE viscosity grade | 80W-90 |
Housing material | Cast iron GG25 |
Weight | 18 kg |
Gear arrangement Increasing | 41 – 42 |
Gear arrangement Reducing | 51 – 52 |
Input shaft Increasing | Y |
Input shaft Reducing | X |
Input power KW / HP Reducing | 8.1 / 11 kW/HP |
Output Torque DaNm Increasing | 7.5 daNm |
Ratio Increasing | 1 : 5 |
Ratio Reducing | 5 : 1 |
Shaft X | 28 (H) |
Shaft Y | SW 36 (A) |
Grinding Workshop
CNC Teeth Machine
CNC Lathe Workshop
Figuring Center
CNC Workshop
Heat Treatment Machine
3D Measurement Machinery
Gear Teeth Profile Test Machines
Heat Treatment Workshop
Tooth Profile Workshop
Q: Are you trading company or manufacturer ?
A: Our group consists in 3 factories and 2 abroad sales corporations.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: How long is your delivery time ? What is your terms of payment ?
A: Generally it is 40-45 days. The time may vary depending on the product and the level of customization. For standard products , the payment is: 30% T/T in advance ,balance before shippment.
Q: What is the exact MOQ or price for your product ?
A: As an OEM company, we can provide and adapt our products to a wide range of needs.Thus, MOQ and price may greatly vary with size, material and further specifications; For instance, costly products or standard products will usually have a lower MOQ. Please contact us with all relevant details to get the most accurate quotation.
If you have another question, please feel free to contact us.
