Agricultural Machinery Baldan 3 Point Hitch Plow/rotary Disc Plow

Agricultural machinery baldan 3 point hitch plow/rotary disc plow Product Description1LY series baldan fish disc plough description : 1LY agricultural disc plough baldan disc plough is specially designed, manufactured and borrowed according the features of foreign disc plough, it is Fully-suspend......

Agricultural machinery baldan 3 point hitch plow/rotary disc plow

Product Description

1LY series baldan fish disc plough description :

1LY agricultural disc plough baldan disc plough is specially designed, manufactured and borrowed according the features of foreign disc plough, it is  Fully-suspended with four wheel tractor. And the discs are rotary motion when tuning the soil. This mounted disc plough is especially suitable for cultivation in the land with weeds, stems and frictional soil with bricks .



Advantages:

1.Disc plough with boron steel disc blade , disc blade with 48-52HRC hardness, wear-resisting tensile.

2. Disc plough hang plate is one whole plate , without welding , it is strong to use.

3. The plough hub is produced with thickned steel , the shaft is made of 80mm round shaft , not the iron casting , so it is strong to use in the hard field.

4. Adjustable angle of disc plough.



Specification

1LY series baldan fish disc plough specification :

Model

unit

1LY-2

1LY-3

1LY-4

1LY-5

Working width

mm

600

900

1200

1500

Working depth

mm

250~300

No. of discs



2

3

4

5

Total weight

kg

350

400

470

560

Matched power

hp

40

60

80

120

Linkage



 Three-point suspension II type



































Product picture show

 Agricultural Machinery Baldan 3 Point Hitch Plow/rotary Disc PlowAgricultural Machinery Baldan 3 Point Hitch Plow/rotary Disc PlowAgricultural Machinery Baldan 3 Point Hitch Plow/rotary Disc PlowAgricultural Machinery Baldan 3 Point Hitch Plow/rotary Disc PlowAgricultural Machinery Baldan 3 Point Hitch Plow/rotary Disc PlowAgricultural Machinery Baldan 3 Point Hitch Plow/rotary Disc Plow
