2RS-0.5 High Speed Two Stage Rotary Vane Electric Vehicle Vacuum Pump for Packing

Raydafon Group's 2RS-0.5 High Speed Two Stage Rotary Vane Electric Vehicle Vacuum Pump for Packing delivers efficient, quiet operation for industrial and automotive applications, ensuring reliable vacuum sealing with advanced technology. Ideal for professionals seeking durable, high-performance solutions, it solves sealing challenges and boosts productivity effortlessly.

Send Inquiry

Product Description

Standard Features
* * Aluminum alloy casing: Alloy casing has high heat dissipation to keep the motor and pump cool, while being light weight and
efficient
* Two-Stage Rotary Vane Deep Vacuum Pump
* Direct drive motor allows for easy start up and is maintenance free
* Direct coupling between the motor and pump results in quiet running and good performance
* Force fed lubrication provides clean, filtered oil to all internal bearings and wearing surfaces regardless of the pump
operation. Cleaner oil reduces ware and break downs.
* Oil drain valve positioned at bottom of oil reservoir.
* Ballast valve on top of the pump
* Great tool for: system evacuation (refrigeration or air conditioning), printing, medical, vacuum packing, hot forming
plastics and other requirements where a high quality pump may be required

Vacuum pump VE215

* Nominal Capacity: 2.6 m3/h
* Final vacuum : <0,005 mbar
* Motor Power: 1/4 HP
* Voltage: 220 V 50 Hz
* Oil volume: 180 ml
* Length x width x height: 308x124x228 mm
* Net weight: 7.5 kg
* Vacuum-Flange: 3/8"/25KF
* Article-Number 1 ph: Z13104

Vacuum pump VE245

* Nominal Capacity: 7.6 m3/h
* Final vacuum : <0,005 mbar
* Motor Power: 1/2 HP
* Voltage: 220 V 50 Hz
* Oil volume: 340 ml
* Length x width x height: 340x138x244 mm
* Net weight: 11.4kg
* Vacuum-Flange: 3/8"/25KF
* Article-Number 1 ph: Z13105

Vacuum pump VE260

* Nominal Capacity: 10.2 m3/h
* Final vacuum : <0,005 mbar
* Motor Power: 3/4HP
* Voltage: 220 V 50 Hz
* Oil volume: 600 ml
* Length x width x height: 395x145x260 mm
* Net weight: 16.5 kg
* Vacuum-Flange: 3/8"/25KF
* Article-Number 1 ph: Z13106
