This splined PTO shaft is built by sturdy steel and features 1-3/8" 6-spline on both tractor and implement ends. It stands out by its adjustable telescoping tube, strong horsepower, and simple replacement. It can serve as farm power tools to improve your work efficiency significantly.
| | | |
|---|---|---|
Heavy-Duty PTO ShaftThis T5 tiller PTO shaft is made of high-quality 20CrMnTi carburized steel and Q345 tube steel, with a black-painted surface to strengthen its durability and stand large impacts, higher torque, and high-speed. | 1-3/8" Connection EndsFeaturing the 6-spline shaft end in both tractor and implement ends, the tractor PTO link shaft can match with 1 3/8" PTO powered farm equipment or machinery. It stands out with superior power-transfer ability. | 43"57" Stretchable LengthThe PTO extender has a flexible expending design with a compressed length: 43"/ 1100 mm and an extended length: 47"/ 1450 mm. At 540rpm with 57hp, 35Kw, and 620 nm torque; 75hp, 55Kw, and torque 500 nm at 1000rpm. |
| | | |
|---|---|---|
Compact Transmit StructureThe PTO shaft is assembled in a compact structure, consisting of a telescoping tube, a universal joint, yokes, a plastic shield and chain for protection. It allows two speeds on both ends and transfers the power into the equipment. | Simple & Quick InstallationThe PTO shaft for the bush hug with spline ends to attach to the implements and tractors quickly. If you want to cut it to the proper length, please read the manual carefully and remember to deburr the edges after cutting. | Wide Range ApplicationThe PTO shaft, proving robust power force to the PTO powered attachment, is most commonly used on mowers, wood chippers, rotary tillers, rotary cutters, brush cutters, hush hug, tractors, etc. |
Package Content
 |  |  | |  | | |
|---|---|---|---|---|---|---|
| T4 PTO Drive Shaft 30-39" | PTO Drive Shaft 35"-45" | PTO Drive Shaft 43"-61" | PTO Drive Shaft 39"-55" | PTO Drive Shaft 43"-57" with Slip Clutch | PTO Drive Shaft 49"-71" with Slip Clutch | |
| Tractor End: | 1-3/8" x 6 Spline | 1-3/8" x 6 Spline | 1-3/8" x 6 Spline | 1-3/8" x 6 Spline | 1-3/8" x 6 Spline | 1-3/8" x 6 Spline |
| Implement End: | 1-3/8" x Round End | 1-3/8" x 6 Spline | 1-3/8" x 6 Spline | 1-3/8" x 6 Spline | 1-3/8" x 6 Spline | 1-3/8" x Round End |
| Compressed Length: | 30" / 750 mm | 35" / 900 mm | 43" / 1100 mm | 39" / 1000 mm | 43" / 1100 mm | 49" / 1250 mm |
| Extended Overall Length: | 39" / 980 mm | 45" / 1150 mm | 61" / 1550 mm | 55" / 1400 mm | 57" / 1450 mm | 71" / 1800 mm |
| At 540RPM: | 35hp, 26Kw, 460Nm | 35hp, 26Kw, 460Nm | 35hp, 26Kw, 460Nm | 35hp, 26Kw, 460Nm | 47hp, 35Kw, 620Nm | 35hp, 26Kw, 460Nm |
| At 1000RPM: | 53hp, 39Kw, 360Nm | 53hp, 39Kw, 360Nm | 53hp, 39Kw, 360Nm | 53hp, 39Kw, 360Nm | 75hp, 55Kw, 500Nm | 53hp, 39Kw, 360Nm |
