PTO SHAFT & GEARBOX FOR PEANUT COMBINES
The PTO drive shaft for agricultural applications consists of two cardan joints and a telescopic coupling.Thecardan joint, consisting of two yokes and a cross, is the element used to transmit the motion between two tiltedaxdes.
PTO SIZE FOR PEANUT COMBINE
| PEANUT COMBINES | PTO SERIES NO. | MIN. LENGTH | MAX LENGTH | TRACTOR END | PEANUT COMBINES |
| Peanut Combine with CV | 2580 | 64.72" | 103.31" | 1-3/8 Z6-QD Pin 80'CV | 1-3/8 Z6-QD Pin |
| Peanut Combine with CV | Series VIII | 38.74" | 48.58" | 1 3/8 Z6-QD Pin 80 CV | 1 3’8 Z6-QD Pin |
| Peanut Combine with CV | Series VIII | 65.24" | 103.82" | 1-3/4" Z20-QD Pin 80 CV | 1-3/8 Z21-QD Pin |
GEARBOX FOR PEANUT COMBINE
