Fast Delivery ARC Teeth 30mm Belt Width 8mm Pitch HTD 8M Steel Timing Pulleys 60 64 72 Teeth
  • Fast Delivery ARC Teeth 30mm Belt Width 8mm Pitch HTD 8M Steel Timing Pulleys 60 64 72 TeethFast Delivery ARC Teeth 30mm Belt Width 8mm Pitch HTD 8M Steel Timing Pulleys 60 64 72 Teeth
  • Fast Delivery ARC Teeth 30mm Belt Width 8mm Pitch HTD 8M Steel Timing Pulleys 60 64 72 TeethFast Delivery ARC Teeth 30mm Belt Width 8mm Pitch HTD 8M Steel Timing Pulleys 60 64 72 Teeth
  • Fast Delivery ARC Teeth 30mm Belt Width 8mm Pitch HTD 8M Steel Timing Pulleys 60 64 72 TeethFast Delivery ARC Teeth 30mm Belt Width 8mm Pitch HTD 8M Steel Timing Pulleys 60 64 72 Teeth
  • Fast Delivery ARC Teeth 30mm Belt Width 8mm Pitch HTD 8M Steel Timing Pulleys 60 64 72 TeethFast Delivery ARC Teeth 30mm Belt Width 8mm Pitch HTD 8M Steel Timing Pulleys 60 64 72 Teeth
  • Fast Delivery ARC Teeth 30mm Belt Width 8mm Pitch HTD 8M Steel Timing Pulleys 60 64 72 TeethFast Delivery ARC Teeth 30mm Belt Width 8mm Pitch HTD 8M Steel Timing Pulleys 60 64 72 Teeth
  • Fast Delivery ARC Teeth 30mm Belt Width 8mm Pitch HTD 8M Steel Timing Pulleys 60 64 72 TeethFast Delivery ARC Teeth 30mm Belt Width 8mm Pitch HTD 8M Steel Timing Pulleys 60 64 72 Teeth

Fast Delivery ARC Teeth 30mm Belt Width 8mm Pitch HTD 8M Steel Timing Pulleys 60 64 72 Teeth

Stock HTD8M Timing PulleyModel: HTD 8MBelt width: 30mmType: BF type (with one hub, with two flange)Teeth type: ARC teethTeeth number:18 20 22 24 26 28 30 32 34 36 38 40 42 44 46 48 50 52 54 56 58 60 64 72.Pitch: 8mmMaterial: 1045 carbon steelSurface: black oxideBore: small holeProduct NameTiming Pul......
Stock HTD8M Timing Pulley
Model: HTD 8M
Belt width: 30mm
Type: BF type (with one hub, with two flange)
Teeth type: ARC teeth
Teeth number:18 20 22 24 26 28 30 32 34 36 38 40 42 44 46 48 50 52 54 56 58 60 64 72.
Pitch: 8mm
Material: 1045 carbon steel
Surface: black oxide
Bore: small hole

Product Name
Timing Pulley
Teeth type
T type:
MXL,XL,L,H,XH,XXH ;T2.5,T5,T10,T20,AT5, AT10,AT20

ARC type:
2M,3M,5M,8M,14M,20M; S2M, S3M, S4.5M, S5M, S8M, S14M.
Timing Pulley Type
AS Type, AF Type,BS Type,BF Type,WF Type

A=Timing pulley without hub
B=Timing pulley with hub
F=Timing pulley with flange
S=Timing pulley without flange
W=The surface of Timing pulley with hole
Surface Treatment
Black oxdizing, Phosphating, Anodize, Galvanized
Material
C45 steel, Aluminum, Plastic, Nylon.
Bore
Pilot bore, Taper bore and Customized bore.
Equipment
Hobbing machine,Drilling machine,CNC machine,Milling machine,Gear shaper,Grinder etc.
Fast Delivery ARC Teeth 30mm Belt Width 8mm Pitch HTD 8M Steel Timing Pulleys 60 64 72 Teeth
Fast Delivery ARC Teeth 30mm Belt Width 8mm Pitch HTD 8M Steel Timing Pulleys 60 64 72 Teeth
Fast Delivery ARC Teeth 30mm Belt Width 8mm Pitch HTD 8M Steel Timing Pulleys 60 64 72 Teeth

Package

We usually package the pulley with carton box or wooden box, we can also packing according to customers demands.

Fast Delivery ARC Teeth 30mm Belt Width 8mm Pitch HTD 8M Steel Timing Pulleys 60 64 72 Teeth
Application
Timing belt pulley or synchronous pulleys rely on accurately meshing with belt teeth and pulley teeth groove;Reliable meshing between belt teeth & those of timing pulley;Available in different size and combinations of materials;Silent power transmission for applications with variable speed pulleys;Economical means to transfer power clean;No slep characteristic.
Fast Delivery ARC Teeth 30mm Belt Width 8mm Pitch HTD 8M Steel Timing Pulleys 60 64 72 Teeth

ever-power

ever-power grouphas manufactured gear pinions, gear racks, timing pulleys, belt pulleys, roller chain, sprockets for years. We have our own factory and professional team.

You will get from our company:
1. Stable Quality.
2. Lower price-Not cheapest but the lowest at the same quality.
3. Good service-Satisfactory service before and after sale.
4. Professional design team and sales department for your service.
5. Direct manufacturers.
6. OEM & ODM available.
7. The punctual delivery of goods,quality and quantity guaranteed.


Our services:
1. Reply your inquiry in 24 working hours.
2. Experienced staffs answer all your questions in fluent English.
3. We are the factory,so we will give you our competitive price for reference and satisfactory services.
4. OEM,buyer design,buyer label services provided.
5. Exclusive and unique solution can be provide to our customer by our well-trained and professional engineers and staffs.
6. 7 days 24 hours online service.

Fast Delivery ARC Teeth 30mm Belt Width 8mm Pitch HTD 8M Steel Timing Pulleys 60 64 72 Teeth
