Double Pitch Big Roller Conveyor Chain DIN Standard Roller Chain C2052 C08A for Conveying Machinery

Product NameDouble pitch big roller conveyor chain roller chain C2052 for conveying machinery Size(Big Roller)JIS/ANSI series: C2042,C2052,C2062,C2062H,C2082,C2082HC2102,C2122,C2162 DIN/ISO series: C208AL,C210AL,C212AL,C216AL,C220AL,C224AL,C232ALSmall RollerJIS/ANSI series:C2040,C2050,C2060,C2......

Send Inquiry

Product Description

Product Name	Double pitch big roller conveyor chain roller chain C2052 for conveying machinery
Size (Big Roller)	JIS/ANSI series: C2042,C2052,C2062,C2062H,C2082,C2082HC2102,C2122,C2162
		DIN/ISO series: C208AL,C210AL,C212AL,C216AL,C220AL,C224AL,C232AL
Small Roller	JIS/ANSI series:C2040,C2050,C2060,C2060H,C2080,C2080H,C2100,C2120,C2160
		DIN/ISO series: C208AL,C210AL,C212AL,C216AL,C220AL,C224AL,C232AL
Pitch	25.4mm-101.6mm
Material	A3 steel,40Mn,45Mn ,stainless steel(SS304,SS316)
Standard	ISO DIN GB ANSI
Length	Standard length 1.524M/box or 10 feet/box
Process	Heat Treatment,Carburization,Quenching. Parts ,Tempering,Black Oxide/Bluing

EVER-POWER GROUP offers a full range of both precision roller chain and engineered.
Applications are varied and range from conveyor, elevator transfer to broad general industrial power transmission specialty
applications with attachments and/or special materials are also available.
* BICYCLE CHAIN: 408,410,415
* MOTORCYCLE CHAIN: 04C, 25H, 06C, T3, 270H,415H, 420, 420L, 425, 428, 428H, 520, 525, 530
* ASA ROLLER CHAIN: 35, 40, 41, 50, 60, 60H, 80, 80H, 100, 120, 140, 160, 200, 240 (Catalog)
* CHAIN (BRITISH STANDARD): 05-B, 06-B, 08-B, 10-B, 12-B, 16-B, 20-B, 24-B, 28-B, 32-B, 40-B (Catalog)
* LARGE PITCH CHAIN: 100, 100H, 120, 120H, 140, 140H, 160, 160H, 180, 200, 240
* EXTEND-PITCH PRECISION ROLLER CHAINS: 208A, 208B, 210A, 210B, 212A, 212B, 216A, 216B,220A,220B,224A,224B,228B,232B
* ROLLER CHAINS FOR BEER BOTTLINET CONVEYORS: CK-70S,CK-100S,CK-100SA,CK-100SC,CK-133XA, CK-140X,
CK-140XA,CK-150X,CK-150S,CK-154X,CK-155X,CK-155XA,CK-160X,CK-160XA,CK-160XB,CK-160XC,CK-165X, CK-165XA, CK-169, CK-180X,CK-180XA,CK-200S,CW-102,CW-127
* IMPLEMENT ROLLER CHAINS FOR CONVEYORS: 81X, 81XH,81XHH,CA550,CA555,CA620
* MULTI STRAND SIZES AVAILABLE; UP TO 5 STRANDS, FOR SELECT SIZES STANDARD ATTACHMENTS AVAILABLE
* CHAINS FROM 04B~16B ARE WITH SPRING CLIPS, OTHERS ARE RIVETED; COTTERED DESIGN IS AVAILABLE FOR SIZES 80 to 240
* STAINLESS STEEL AND NICKEL PLATED CHAIN IS AVAILABLE; SPECIAL DESIGN ALSO AVAILABLE (i.e., OVEN CONVEYOR)
* Special Chain size 205, 662, 667H, 667X, 667XC, 667K, 667KC, 667XH, 88K AND FOR OTHER SIZE NOT LISTED PLEASE CHECK WITH OUR
CATALOG

The above represents some of the common chain sizes offered. Other chain sizes can be considered upon request.

Click here to contact us for samples！

Please click on the photos below to visit their websites.

Click here for more details and models！

We have more than 10 years of production experience ,professional equipment and workers.

We are specialized in manufacturing transmission and conveyor roller chains in China.
We also can produce all kinds of non-standard roller chain according to your drawing.

Q:What is the strength of your company?
A:We have a engineer team,who have well experienced on products and machine designs.We can help you to solve the problem you meet.

Q:How about you quality?
A:We have our own prcoessional factory and worker,so believe that our products have advange over our competitors.

Q:What is you MOQ?
A:Minimum order quality is 1 piece.

Q:Could you produce customized product according to your drawing or sample?
A:Yes.We have abundant experience in the production of non-standard products.

Packaging:
Chain+Plastic Bag+ Carton+Wooden case( If you have other requirements, we can customized according to customer requirements packaging. )

Shipping :
1.Most of the standard ones are in stock which we can send in 3-10 days after inspection and package.
2. Customized products delivery time should be determined according to the number.
