Coups Customized High Speed Shaft Single Composite Disc Membrane JMB Series Diaphragm Coupling

Product ApplicationIt can be widely used in power plant, petrochemical plant, steel plant, mining machinery, cement machinery and other industries, especially for mine fan, rope hoist and other places with high safety coefficient requirements. SPECIFICATIONS FOR 25 TON CRAWLER EXCAVATORSeries JMB D......

Send Inquiry

Product Description

Product Application

It can be widely used in power plant, petrochemical plant, steel plant, mining machinery, cement machinery and other industries, especially for mine fan, rope hoist and other places with high safety coefficient requirements.

SPECIFICATIONS FOR 25 TON CRAWLER EXCAVATOR
Series JMB Diaphragm coupling	Model	HS	HS6-100
		Rated Value	K·KW/rpm	0.07
		Maximum speed of revolution	rpm	33500
		Axial	mm	1.5
		Rotary Inertia	Kg.m²	0.0122
Allowable deviation	Angular	degree	1/2
		Radial	mm/mm	0.0087
		Axial	mm	1.5
Coupling weight	L₁min weight	kg	7.65
Coupling weight		L₁each additional weight	kg	0.654

Main Features

1)Double-diaphragm small axial coupling is a patent product developed by our factory, the patent number is zl.99 2 46247.9

2)Compact structure, adjustment capacity, impact resistance and vibration reduction performance than single diaphragm to wheel 35% ~ 40%

3)In the case of accidental damage to the diaphragm, the plum flange can continue to transmit torque, with good safety performance

4) Easy installation and disassembly, no need to move motor or reducer

JM series diaphragm coupling

JM diaphragm coupling is the most representative metal disturbance coupling, which can be used in all kinds of mechanical equipment.

SRC cross shaft

SRC cross shaft universal coupling is suitable for steel rolling machinery

Bibby coupling

91.8%Response Rate

Ever-power transmision group is a professional manufacturer of couplings and universal joint shafts in China's heavy machinery industry, and is affiliated to Coups Industry Group.
Ever-power transmision group is one of the largest coupling manufacturers in China which own many patent in coupling. And also is the Sinopec member unit has passed ISO9001: 2000 international quality system certification. It is mainly engaged in research and development, design, production and sales of power transmission system components. The universal coupling manufacturing technology has filled the gap in this technology in China.
Engaged in the production of various national standard, non-standard couplings, and the manufacturing and processing of auxiliary equipment in various mining, metallurgy, coal, chemical and other industries. " Triocircle coupling, the production capacity of 200 million yuan (RMB), the current annual output value of 120 million yuan (RMB), has a solid market position in the domestic market.

Before
1.Any questions about our items will be answered within 24hrs.
2.We could send relevant product information to the E-mail.
After
1.If there is a quality problem,the manufacturer is responsible for the repair within the warranty period.
2.If you have any problems with the use of the product, please contact us (E-mail or phone).

Q1. Can we visit your factory?
A:It's our pleasure, just inform us before you coming, we will give you some information about our factory.
Q2.What infomation should I tell you to confirm the product?
A: Model/Size, Shaft diameter, hole diameter& Order quantity etc.
Q3.How long is your delivery time?
A: It is according to quantity. Generally it is 5-10 days if the goods are in stock. or it is 15-60 days .Please contact us to confirm according to your requirement.
Q4.Can I add my logo on the Coupling ?
A:Yes,OEM and ODM are available.
