BPB1,BPB2,BPB3 has similar structure with BHR1,BHR2,BHR3,connection dimension a little different, according to most European and US standard. TypeDisplacement(ml/r)Rated Flow(l/min)Max input pressure (Mpa)Max cont back pressure(Mpa)Normal Input TorqueBPB1,2,3-8080817.52.5<2.5BPB1,2,3-1001001017......

Send Inquiry

Product Description

BPB1,BPB2,BPB3 has similar structure with BHR1,BHR2,BHR3,connection dimension a little different, according to most European and US standard.

Type	Displacement (ml/r)	Rated Flow (l/min)	Max input pressure (Mpa)	Max cont back pressure(Mpa)	Normal Input Torque
BPB1,2,3-80	80	8	17.5	2.5	<2.5
BPB1,2,3-100	100	10	17.5	2.5	<2.5
BPB1,2,3-125	125	13	17.5	2.5	<2.5
BPB1,2,3-160	160	16	17.5	2.5	<2.5
BPB1,2,3-200	200	20	17.5	2.5	<3
BPB1,2,3-250	250	25	17.5	2.5	<3
BPB1,2,3-280	280	28	17.5	2.5	<3
BPB1,2,3-315	315	32	17.5	2.5	<3
BPB1,2,3-400	400	40	17.5	2.5	<3
BPB1,2,3-500	500	50	17.5	2.5	<3
