| BM3 TECHNICAL DATA | ||||||||||
| TYPE | BM3Y-80 | BM3Y-100 | BM3Y-125 | BM3Y-160 | BM3Y-200 | BM3Y-250 | BM3Y-315 | BM3Y-400 | BM3Y-500 | |
| BM3YS-80 | BM3YS-100 | BM3YS-125 | BM3YS-160 | BM3YS-200 | BM3YS-250 | BM3YS-315 | BM3YS-400 | BM3YS-500 | ||
| BM3YW-80 | BM3YW-100 | BM3YW-125 | BM3YW-160 | BM3YW-200 | BM3YW-250 | BM3YW-315 | BM3YW-400 | BM3YW-500 | ||
| Displacement(ml/r) | 80.5 | 100.5 | 126.3 | 160.8 | 200.9 | 252.6 | 321.5 | 401.9 | 476.5 | |
| Max.Pressure.Drop(Mpa) | cont. | 20.5 | 20.5 | 20.5 | 20.5 | 20.5 | 20 | 20 | 15.5 | 12 |
| int. | 27.5 | 27.5 | 27.5 | 26 | 25 | 25 | 24 | 19 | 14 | |
| peak. | 29.5 | 29.5 | 29.5 | 28 | 27 | 27 | 26 | 21 | 16 | |
| Max.torque(N.m) | cont. | 226 | 282 | 355 | 451 | 564 | 684 | 870 | 813 | 728 |
| int. | 293 | 365 | 459 | 559 | 672 | 845 | 1032 | 1021 | 903 | |
| peak. | 306 | 383 | 481 | 588 | 708 | 891 | 1091 | 1141 | 1044 | |
| Max. Speed (cont.)(r/min) |
805 | 745 | 590 | 465 | 370 | 295 | 230 | 185 | 155 | |
| Max.Flow(cont.)(L/min) | 65 | 75 | 75 | 75 | 75 | 75 | 75 | 75 | 75 | |
| Max.Output.Power(cont.)(Kw) | 16 | 18 | 18 | 18 | 18 | 18 | 17 | 11 | 9 | |
| Weight(kg) | 9.8 | 10 | 10.3 | 10.7 | 11.1 | 11.6 | 12.3 | 13.2 | 14.3 | |
Intermittent operation the permissible values may occur for max.10% of every minute
Peak load:the permissible values may occur for max.1% of every minute
