Worm Reduction Gearbox

Raydafon Automation's Gearbox product lines offer high precision at affordable prices! The Planetary Gearbox product offering includes both In-Line and Right-Angle configurations, built with the design goal of offering a cost-effective gearbox, without sacrificing quality. These Planetary Gearboxes are available in sizes from 40mm to 180mm, ideal for motors ranging from NEMA 17 to NEMA 42 and larger. The Spur Gearbox line offers an efficient, cost-effective option compatible with Raydafon Automation's AC Induction Gear Motors. Raydafon Automation's Gearboxes are offered in up to 30 different gear ratios, with torque ratings up to 10,488 in-lbs (167,808 oz-in), and are compatible with most Servo,

SureGear Planetary Gearboxes for Small Raydafon Motors

Features

Wide range of ratios (5, 10, 25, 50, and 100:1)

Low backlash of 30 arc-min or less

20,000 hour service life

Maintenance free; requires no additional lubrication

NEMA sizes 17, 23, and 34

Includes hardware for mounting to SureStep stepper motors

Optional shaft bushings available for mounting to other motors

1-year warranty

Applications

Material handling

Pick and place

Automation

Packaging

Other motion control applications requiring a Raydafon input/output
