Tractor Pto Gearbox

Hydraulic Tractor PTO Gearbox to Suit Group 2/3 Pump 1:3 Ratio 70004-4

These over-gears are designed for connecting hydraulic gear pumps to farm tractor power-take-offs (PTO’S).

The output speed of a PTO ( Power take off ) is 540RPM, Giving a pump shaft speed of 1620 RPM. Different input speeds can also be suitable, provided that over-gear output speed does not exceed 3000 RPM.

SPECIFICATION:

Housing: Aluminium

Shafts & Gear Material: Steel

Lubrication: SAE 90 Gear Oil

Working Temperature: 120°C Max

Female PTO Shaft 1 3/8 Quick Fitting

ASAE 1 3/8 Z6 DIN 9611 A

Pump Connection: DIN 5482 A 35 x 31 18 Tooth

Ratio: 1:3

Rating: 20Kw
