Driveline Gearbox Of Irrigation System
Driveline Gearbox Of Irrigation System |
 | 725 Series Gearbox: Application: Final Drive Wheel boxes for all electric drive and Hydraulic powered Center Pivot / lateral move Systems Models Include: 725 - U, 50:1 worm gear ratio: Standard gear ratio for most systems. 725 - UV, 52:1 Worm gear ratio: Select gear ratio to match those provided by original equipment manufacturer. 725 - UT , Towable 50:1 worm gear ratio: For use on Towable systems to provide free wheeling hubs. 725 UHYD 50:1 Worm gear ratio: For Use on Hydraulic powered systems only |
| 730 Series Gearbox: Application; Heavy Duty Final drive wheel boxes with 2 1/2" output shaft for Longer spans, Larger wheels, and heavier towers on all electric drive and Hydraulic powered Center Pivot and lateral/linear move Systems Models Include: 730 - U, 50:1 worm gear ratio: Standard gear ratio for most systems. 730 - UT , 50: worm drive ratio: For use on Towable systems to provide free wheeling hubs |
 | 740 and 745 Series Gearbox: Application: Ultimate Duty Final drive wheel boxes with larger bearings and available with 2 1/4" or 2 1/2" output shaft for Longer spans, Larger wheels, and heavier towers on all electric drive and Hydraulic powered Center Pivot / lateral move Systems |
 | 760 Series Gearbox Application: Larger diameter Bull Gear to provide 20% higher output torque on all electric drive and Hydraulic powered Center Pivot / lateral move Systems Models Include: 760 - U, 50:1 worm gear ratio: Standard gear ratio for most systems |
 | 725 T-NT (Tow - Non Tow) Series Gearbox Application: Towable Final drive wheel box, provide the ability to disengage the worm gear and allows users of all electric drive and Hydraulic powered Center Pivot Systems and lateral/linear move systems to move systems from one area to another Models Include: 725 - TNT, 50:1 worm gear ratio Standard gear ratio for most systems. 725 - TNT, 52:1 worm gear ratio: Select gear ratio to match those provided by original equipment manufacturer |
 | 740 T-NT (Tow - Non Tow) Series Gearbox Application: Towable Final drive wheel box, provide the ability to disengage the worm gear and allows users of all electric drive and Hydraulic powered Center Pivot Systems and lateral/linear move systems to move systems from one area to another Models Include: 740 - TNT-U, 50:1 worm gear ratio Standard gear ratio for most systems. 740 - TNT-UV , 50:1 worm gear ratio: Select gear ratio to match those provided by original equipment manufacturer |
 | Speed Gearbox Application: Multiple input and multiple speed output planetary style gearbox for use on irrigation hose travelers |
 | Bolt on Towable Hub Application: Converts standard gearboxes for use in towable applications Model: BT-4B: Converts any standard eight bolt gearbox for towable applications. 5/8" Stepped Tow Pin Kit: Used in conjunction with BT-4B, Towable hub assemblies and UT style gearboxes. 3/4" Tow Pin Kit: Used in conjunction with BT-4B, Towable hub assemblies and UT style gearboxes to match hole sizes of gearboxes provided by Original Equipment Manufactures |
